LAAKISTA VAINAA

Tällä paketilla pamautat tajuntasi kankaalle! Uskomaton tehopaketti, jonka hintaa on vaikea lyödä! Sarja sisältää SD8000.1 EVO 4.0 - 1ohm vahvistimen, sekä GZIW 12XSPL-D2 subwooferit!

Tekniset tiedot:

Vahvari:

Compatible with SD-RLC Remote level control.

POWER RATING
12,6V: @ 2Ω: 1 x 8000 W RMS
12,6V: @ 4Ω: 1 x 5280 W RMS
14,4V: @ 2Ω: 1 x 8920 W RMS
14,4V: @ 4Ω: 1 x 5887 W RMS

CROSSOVER
HPF: 5Hz - 80Hz
LPF: 50Hz - 20Khz

DIMENSIONS
L: 35,4cm
W: 22,5cm
H: 7,1cm

FREQUENCY
(-3dB): 5Hz-20Khz
THD: 0,08%

Älä kytke vahvistinta alle nimelliskuorman!
Do not run your amp under rated impedance!

Subbarit:
- 12″ XSPL Subwoofer
- Progressive 2-layer spider
- Voice coil 63 mm / 2.5″
- Impedance 2 x 2 Ohm
- Re 4.33 Ohm
- Fs 32,5 Hz
- Qms 10.76
- Qes 0.79
- Qts 0.73
- Vas 40.4 L
- Le 2.48 mH
- Mms 231 gr
- Bl 15.9
- Xmax 34 mm / 1.34″
- Effiency ( SPL 1w / 1m )
- Power handling ( SPL ) 1000 Watts
- Rec. amplifier power 500 - 1000 Watts
- Outer diameter 310 mm / 12.2″
- Mounting cut out 285 mm / 11.22″
- Mounting depth 162 mm / 6.38″

Recommended enclosures:
- Vented 45L net
- Port 10cm / 4″, length 21cm

- Bandpass ( 4th order ) 25L net sealed / 40L net vented
- Port 10cm / 4″, length 11cm
- Tuning frequency Fb 57 Hz
-Bandwith 35 - 100 Hz
